Twin-triode tube 6CS7 for the first-stage amplification. WBT type speaker terminals. Heavy-duty output transformer for 50W grade amplifiers. Large capacity choke-coil: 5H350mA Dumper tube 6CJ3 (for Colour TV use) is applied to delay a supply of high voltage (B-Voltage) to output tubes in order to protect output tubes from damages and to longer the life. All high-end audio grade electrical components (condensors, resistors) Operation lamp indicator Succeeding a front design of CS-300/CS-300X. 24K Gold-Plated Knobs. Side Wood-Panels.
Power Amp Direct Switch. (All functions by-pass only excepting Volume control) Muting Switch. Stereo/Reverse Switch. Variable Output Impedance: 4/6/8/16 Ohms. Tape Monitor Switch. Bass Boost Switch. Headphone Output. Speaker/Headphone Selector Switch. Tube Indicator Lamps. Operation Lamp Indicator.
TUBES EQUIPPED (4) 6L6GC (5881) SOVTEK, (EL34/6CA7 - Option) (4) 6CS7 (1) 6CJ3 OUTPUT POWER 32W x 2 (6L6GC) at 1KHz. 28W x 2 (EL34) at 1KHz. FREQUENCY RESPONSE 10Hz - 100KHz. (-0.1dB) DISTORTION 0.7%(10W) INPUT SENSITIVITY 900mV at 20W OUTPUT IMPEDANCE 4/6/8/16 Ohms (Selectable) POWER CONSUMPTION WEIGHT 22.5 Kgs. DIMENSIONS 450 (W) X 360 (D) X 142 (H) mm ATTACHMENT Detachable AC Power Cable x 1
