Product Overview
Luxman begins to mark their 100th Anniversary with "Z"!
The L-507z joins Luxman’s integrated amplifier range with numerous advances and features our newly designed “LIFES1.0” distortion canceling feedback engine. “LIFES” is a significant evolution from “ODNF” circuitry, which has long been a key advantage of Luxman amplifiers since its 2010 introduction in our X-series. The robust L-507z marks the beginning of Z-Series, all being developed to include this latest “LIFES” high-quality amplification system, a core technology also shared with our new flagship M-10x stereo/mono power amplifier. In addition, new user features enhance both convenience and performance required by today’s music listeners. Updated front panel VU meters combine with a 7-segment LED display to improve visibility of volume levels from any listening position. Alongside the standard 6.3 mm headphone jack is a new 4mm “Pentaconn” balanced output jack for better L-R separation. Rear- panel 12 volt trigger connections are now incorporated enabling more convenient integration among automated systems or a home-theater.
Specifications:
Rated output - 110W + 110W (8Ω) 220W + 220W (4Ω) Input Sensitivity / Input Impedance PHONO (MM): 2.5mV / 47kΩ PHONO (MC): 0.3mV / 100Ω LINE: 180mV /47kΩ BAL.LINE: 180mV / 79kΩ MAIN-IN: 1.05V / 47kΩ Output voltage - PRE OUT: 1V Frequency Response - PHONO: 20Hz to 20kHz (within ± 0.5dB ) LINE: 20Hz to 100kHz (within -3.0dB) Total harmonic distortion - 0.007% or less (8Ω, 1kHz) 0.03% or less (8Ω, 20Hz to 20kHz) S / N ratio (IHF-A) - PHONO (MM): 91 dB or more/ PHONO (MC): 75 dB or more LINE: 105 dB or more Volume control - New LECUA 1000 Amplifier circuit - LIFES 1.0 Output configuration - Bipolar 3 parallel push-pull Power transformer - EI type 560VA Damping factor - 300 (by EIAJ current injection method) Tone control - BASS: ± 8dB at 100Hz TREBLE: ± 8dB at 10kHz Power-supply voltage - AC110V (50 / 60Hz) power consumption - 300W / 86W (no signal ) 0.4W (standby) External dimensions - WxDxH 17 1/4 x 7 1/16 x 17 7/8" 440mm x 454mm x 178 mm Depth includes front knob 20 mm and back terminal 27 mm Weight 25.4kg (main body), 29.4kg (standard packaging) Remote control (RA-17A) warranty - 3 years
