Tap into advanced Yamaha digital signal processing with CINEMA DSP HD3, utilize the best built-in functions for customization and enjoy the latest home theater technologies that are offered today. Now with MusicCast, this device can be expanded to deliver wireless multiroom audio playback, all controlled by a simple app.
The AVENTAGE line of high-performance AV receivers is based on the audio design concept of providing a massive, full-bodied sound for movie sound effects and the accurate reproduction of music sources. By expertly harmonizing traditional and advanced technologies, every factor that affects sound quality, from materials and parts to construction, layout, vibration damping (unique foot) and “fine-tuning” the sound, is handled with no other thought than to achieve the best possible audio quality. As a result, every AVENTAGE model has the ability to reproduce the most subtle details of high-definition sound, so that listeners can enjoy a truly high-class sound studio experience at home.
Electrical noise may be generated from connections with other AV components, including the connections between them as well as from external noise sources. To ensure that the CX-A5100 is not affected by this distortion, it uses balanced connections that are highly noise resistant t the same type generally used in pro audio equipment. Even the unbalanced RCA connection uses a ground-sensing transmission method that achieves a simple and balanced transmission. When each channel is used independently, the impact of noise flowing between the preamp and power-amp is removed, minimizing sound quality deterioration due to the connection. XLR terminals allow for the use of long cables that may be needed to connect a subwoofer. The CX-A5100 also has a balanced audio input connection to high-grade source components such as CD players.
Every single part in an AV receiver affects the sound quality. For AVENTAGE models, extra time is taken to find (or develop) the exact parts needed to achieve the highest performance possible. Sound technicians go through a testing process to, in effect, “tune” the receiver’s sound.
All channels use ultra-high performance ESS ES9016 DACs, which provide 192 kHz / 32-bit processing with a superior SN ratio and high dynamic range, ensuring faithful reproduction from Blu-ray Discs and other players, as well as from high-resolution source inputs over the network. Matched to the design of the DAC circuitry, which achieves stable ground potential (DAC on Pure Ground), they provide high-precision D/A conversion. A new Volume IC realizes low noise and superior sound orientation and a superior low-jitter clock circuit is used for clear and vivid network audio. In addition, the internal design separates the power supplies to the analog circuit boards, eliminating high frequency noise interference from the digital circuitry. The shielded power supplies restrict noise radiation and the large power transformer minimizes vibration.
As part of this preamp processors no compromise design, Yamaha created an advanced chassis with strong rigidity. Chassis stiffness is enhanced by a three-ply structure that incorporates an independent top cover, aluminum side panels and an H-shaped cross frame. The ART (Anti-Resonance Technology) Wedge in the center of the bottom cover acts as an additional vibration countermeasure for the internal circuits and delicate parts
All of the AVENTAGE components feature the same sleek, clean design, with an elegant aluminum front panel and silky touch volume/selector knobs. The aluminum front panel is used to effectively shield sensitive circuitry from external noise and electronic radiation generated by dimmer switches, fluorescent lighting, video monitors and so on. This ensures optimum sonic performance in the widest range of installation environments.
Amazon Alexa-enabled devices — including Echo, Dot, Tap and Show — can now control key functions of any MusicCast product using voice commands. Discover a new, exciting way to control music and entertainment experiences in your home.
The CX-A5100 is equipped with Bluetooth® functionality to let you easily enjoy wireless music playback from smartphones and other devices. The Compressed Music Enhancer from Yamaha is now optimized for Bluetooth audio transmissions to ensure that your music will have vivid, lively sound quality during wireless playback.
Wireless operation more convenient than ever. The CX-A5100 is equipped with the latest Bluetooth technology to stream music to Bluetooth speakers for added audio coverage or to Bluetooth headphones for private listening.
This AV receiver completely supports with the latest HDMI standards. Thanks to transmission of 4K video at 60 frames per second pass-through, you can fully enjoy the high definition video quality of 4K without degradation. It also adheres to the HDCP2.2 copyright protection standard for 4K video transmission. It also supports HDR (High Dynamic Range) Video which provide enhanced picture quality by simultaneously enabling greater detail for both the dark and bright parts of an image. Furthermore it supports wider color gamut of BT.2020 pass-through.
|Composite Video Inputs:||5|
|Component Video Inputs:||3|
|Coaxial Digital Audio Inputs:||3|
|Component Video Outputs:||1|
|Composite Video Outputs:||1|
|Optical Digital(Fiber Optic) Audio Inputs:||3|
|Remote Control Type:||1 IR Remote Control|
|HDMI Standby Pass-through:||Yes|
|AM/FM Tuner Built-In:||Yes|
|Power Off Consumption (watts):||0.1|
|Product Weight (lbs.)||29.8|
|Analog Audio(RCA) Input||7|
